Eclipse BS Spare Parts Guide
To find the reference for the part you want, check the diagram below. Click the corresponding Part Number on the right for price details and for the link to buy the item.
Part Number
- Part Code: IWS-6011
- Part Name: Needle Cap
- Part Code: IWS-6022
- Part Name: .35mm Nozzle Cap
- Part Code: IWS-6042
- Part Name: .35mm Nozzle
- Part Code: IWS-6051
- Part Name: Packing O-Ring
- Part Code:
- Part Name: Airbrush Body
- Part Code: IWS-5801
- Part Name: Packing Valve Piston
- Part Code: IWS-6081
- Part Name: Air Valve Guide Body
- Part Code: IWS-6091
- Part Name: Air Valve Plunger with O-Ring
- Part Code: IWS-5104
- Part Name: Air Valve Spring
- Part Code: IWS-6111
- Part Name: Air Valve Guide
- Part Code: IWS-6121
- Part Name: Main Trigger Lever
- Part Code: IWS-7251
- Part Name: Needle Packing Screw with Teflon
- Part Code: IWS-7151
- Part Name: Needle Chucking Guide
- Part Code: IWS-1351
- Part Name: Needle Spring
- Part Code: IWS-1702
- Part Name: Spring Guide
- Part Code: IWS-6172
- Part Name: 0.35mm Needle for BS
- Part Code: IWS-1202
- Part Name: Needle Chucking Nut
- Part Code: IWS-6191
- Part Name: Single Cut Handle
- Part Code: IWN-13012
- Part Name: Slide Cam Spring
- Price: £8.99
