Iwata Eclipse CS Spare Parts Guide
Iwata Eclipse CS
To find the reference for the part you want, check the diagram below. Click the corresponding Part Number on the right for price details and for the link to buy the item. You will NOT need a nozzle wrench to take out the nozzle inside the Eclipse CS airbrush. Unlike other Iwata airbrushes the Eclipse CS has a special ‘floating nozzle’ which is easier and less delicate to take apart to change. The little spanner is used to take the head off to get into the nozzle area.
Part Number
- Part Code: IWS-6011
- Part Name: Needle Cap
- Part Code: IWS-6022
- Part Name: Nozzle Cap
- Part Code: IWS-6042
- Part Name: Nozzle (E3)
- Part Code: IWS-6051
- Part Name: Packing (O-Ring)
- Part Code: IWS-6062
- Part Name: Body (not available with GraphicAir)
- Part Code: IWS-5801
- Part Name: Packing Air Valve Piston O-Ring
- Part Code: IWS-6081
- Part Name: Air Valve Guide Body with O-Ring
- Part Code: IWS-6091
- Part Name: Air Valve Plunger with O-Ring
- Part Code: IWS-5104
- Part Name: Air Valve Spring
- Part Code: IWS-6111
- Part Name: Air Valve Guide Screw
- Part Code: IWS-6121
- Part Name: Main Lever (Trigger)
- Part Code: IWS-7251
- Part Name: Needle Packing Screw
- Part Code: IWS-7151
- Part Name:
- Part Code: IWS-1351
- Part Name: Needle Spring
- Part Code: IWS-1702
- Part Name: Spring Guide
- Part Code: IWS-6172
- Part Name: Needle (E3)
- Part Code: IWS-1202
- Part Name: Needle Chucking Nut
- Part Code: IWS-6191
- Part Name: Single Cut Handle – Eclipse
- Part Code: IWS-6181
- Part Name: Iwata Lid – Eclipse
- Part Code: IWS-6021
- Part Name: Nozzle Cap (E5)
- Part Code: IWS-6041
- Part Name: Nozzle (E5)
- Part Code: IWS-6171
- Part Name: Needle (E5)
