Art No: C-TC-610H-N – Sparmax TC-610H-N Compressor with  2.5L Tank

The Sparmax TC-610H-N is an updated model of the popular TC-610H airbrush compressor, featuring a new case design with top mounted pressure adjustment, pressure gauge & removable twin airbrush holders. The Sparmax TC-610H-N Compressor provides a powerful airflow, delivering close to doubled airflow which can meet the needs of airbrush enthusiasts and professionals alike. It features a 2.5L air tank system which helps to provide a consistent airflow with minimal pulsations. It has ample power for any airbrushing task and is suitable for professional airbrush users doing general or extended airbrush applications.

Just like the previous TC-610H, the TC-610H Plus is a powerful, quite & reliable oil free automatic single piston airbrush compressor fitted with a 2.5L air tank.

The TC-610H Plus is automatic – when the air tank pressure falls below 40psi, the compressor runs to recharge the tank back to 60psi & then switches off – the compressor running to the demand of the air tank, rather than switching on/off every time the airbrush trigger is pressed.

The Sparmax TC-610H compressor features:

• Piston Compressor
• Oil-free, fully automatic and pulsation-free.
• Max. Pressure: 7.0 bar, but is factory limited to 4.2 bar.
• Automatic switch-off (with automatic pressure switch from 40-60 PSI = 2.75-4.2 bar).
• Suction power: 23-26 l/min.
• Noise level: approx. 35 – 43 dB / A (very quiet).
• Tank 2.5 L
• Tank with pressure relief valve.
• Air and condensate drain valve.
• Operating voltage: 220 V / 50 Hz / 70 W / 1600 rpm.
• 130 watts.
• Weight without packaging: 6.0 kg.
• 1 spiral air hose approx. 3 m with G1/8 inch connections.
• Duty cycle: 60 minutes continuous use. Please allow the motor to rest for at least 20 minutes after each cycle of continuous use.

Suitable for running two of the following airbrushes (or similar) concurrently:

• Sparmax SP35, SP35C, MAX-3, MAX-4, HB-040, SP-20X, DH-125
• Sparmax GP-35, GP-50
• Premi Air G35
• Neo for Iwata
• Iwata Revolution BR, CR, SAR, BCR, TR1, TR2, M1, M2
• Iwata Eclipse (or one G3, G5 or G6)
• Iwata HP
• Iwata HP-Plus
• Iwata Hi-Line
• Iwata Hi-Line HP-TH (will only run one)
• Iwata Custom Micron
• Iwata Kustom series (or one HP-TH)
• Paasche CC
• Paasche F
• Paasche Talon
• Paasche V
• Paasche VJR
• Paasche VSR90
• Paasche VV
• Badger 100
• Badger 150 (except with HD head)

Suitable for running one of the following airbrushes, small spray guns or similar:

• Iwata Eclipse G3
• Iwata Eclipse G5
• Iwata Eclipse G6 (not fan pattern)
• Iwata Hi-Line HP-TH
• Paasche H
• Paasche HS
• Paasche VL
• Paasche VLS
• Paasche MIL-SET
• Paasche AEC
• Paasche 200T (at low pressure for tanning)
• Badger 150 HD
• Badger 155
• Badger 175
• Badger 200
• Badger 250
• Badger 260
• Badger 350
• Sparmax GP-850
• Flake King 500

610H-N Manual
